Agricultural Tillage Equipment Disc Plough Plow Tractor Mounted 40-160HP

Name: Agricultural Tillage Equipment Disc Plough Plow Tractor Mounted 40160HP
Brand: Xinyi
Price: 500 USD

Quality Agricultural Tillage Equipment Disc Plough Plow Tractor Mounted 40-160HP for sale

Certification : CE,ISO

Brand Name : Xinyi

Model Number : 1LY

Place of Origin : China

MOQ : 1

Price : 500-1100

Payment Terms : T/T

Supply Ability : 500pieces/Month

Delivery Time : 10 days

Packaging Details : Customizable

Model NO. : 1LY-330

Application Field : Agriculture

Farming Policy : Dry Cultivating Machinery

Power Source : Tractor

Operation : Soil Preparation Machinery, Continuous Running Operation

Traction Type : Traction

Drive Type : Gear Drive

Arbor Configuration : Vertical Shaft

Warranty : 1year

Working Depth : 250-300mm

Working Width : 600-1800mm

Linkage : Three Pointed

Matched Power : 40-160HP

Diameter of Disc : 660mm/710mm

Transport Package : Iron Box

Specification : 2-6 PCS

Trademark : Xinyi

Origin : China

HS Code : 8432100000

Contact Now

YuCheng Xinyi Machinery Factory
Product Technical Parameter

The 1LY disc plough is fully attached to the tractor. During the working process, the disc rotates to turn over the soil. Specifically, it is highly suitable for operation in fields that have grasses, crop or plant straws and stems, where there is high soil resistance, as well as fields with numerous stones and broken bricks, etc. In the field, it excels at cutting grasses and straws and won't be blocked by grasses, soil or stones, etc. Its working efficiency is high. It performs well in quality during operation. It is convenient to adjust, sturdy and long-lasting. Due to the employment of 8 mm rectangular tubes and over 20 years of experience in manufacturing agricultural tools, the main frame of our disc plough is robust and durable. Thanks to the discs manufactured by our own factory, by using Anshan and Lingyuan steel, the finest steel in China, the discs are hard, wear-resistant and not prone to damage. Given our factory's position, we are able to supply all the accessories, all of which are produced by ourselves.

Main Feature

Our disc plough is fitted with 26"x6mm blades manufactured in - house. Constructed from Anshan and Lingyuan steel, the finest in China, these plough blades offer superior quality. The MF disc plough features an 8mm - thick tube, ensuring a robust and long - lasting structure. Additionally, the plough legs have undergone special heat treatment, enhancing their durability.

Type	1LYX-230	1LYX-330	1LYX-430	1LYX-530	1LYX-630
Working width (mm)	600	900	1200	1500	1800
Working depth (mm)	250-300
No. of disc (pc)	2	3	4	5	6
Dia of disc (mm)	660/710
Weight (kg)	320	400	490	650	750
Linkage	Three point mounted
Matched power (hp)	40-50	60-80	80-100	100-120	120-160

Agricultural Tillage Equipment Disc Plough Plow Tractor Mounted 40-160HP

Normal packing or According to your requirement.

Safe, complete and fast delivery of goods to customers.

1,All products enjoy 12 months warranty period. The warranty period is calcualted from the date of bill of lading .

2,We provide our clients with genuine spare parts with the highest quality,exact fitness .If needs,please submit your spare parts request to us,and list products name ,description of required parts.we guarantee that your request will be handled quickly and appropriately.

3,We can also provide training services to different users.

1. Q: Manufacturer or trading company?
A:We're a manufacturer. We have physical manufacturers.
2.Q: Full price list for these products
A: If you need the price list for these products, please notify the product model so that I can quote you
accordingly. Please understand we have a very wide product range, we don't usually offer full
products price list.
3. Q: Business terms
A: Shipment time: 25-40days after your payment
Shipment: By sea
Loading port: Qingdao port, China
Destination port: ...To be advised
Payment: T/T , L/C
Warranty: 1 year
4.Q:How can I order from you?
A: Please send us your enquiry list; we will reply you within two working days.
5.Q:If the finger I look for are not in your catalogue, what should I do?
A: We can develop it according to your drawing or sample.
6. Q: Why choose Xinyi for cooperation?
A: Comparing with our competitors, we have much more advantages as follows:
1. More than 25 years in manufacturing farming machine.
2. More Professional Sales staffs to guarantee the better service.
3. More agri machines for your choice.
4. More New products into your range to avoid price competition.
5. Larger quantity production and shipment.
6. Better quality to guarantee better Credit.
7. Faster delivery time: Only 7 days.
8. More stick quality checking before shipment.
9. More reasonable after-sales service terms.
10. More famous brand: "XINYI" brand and "CE"ceitification.
11.Lower repair rate and bad review rate.
12. Have received unstinting support from the Chinese government.

If you have any questions, please do not hesitate to contact me
